The 50 tons vertical LCO2 vacuum insulated cryogenic storage tank is engineered for safe, stable, and long-term storage of liquid carbon dioxide in industrial, food-grade, and energy-related applications.
Designed with double-wall vacuum insulation technology, this vertical cryogenic liquid storage tank minimizes heat ingress, controls evaporation loss, and ensures reliable operation under continuous working conditions.
It is widely deployed in:
Beverage carbonation plants
Food processing factories
CO₂ recovery systems
Dry ice production lines
Chemical processing facilities
Industrial gas distribution stations
This 50 tons vertical LCO2 vacuum insulated cryogenic storage tank adopts:
Inner vessel: low-temperature pressure vessel material
Outer shell: carbon steel protective jacket
High vacuum multilayer insulation system
Safety valve and vacuum protection assembly
Liquid level, pressure and temperature monitoring interfaces
The vertical structure reduces footprint and is suitable for fixed installation in industrial sites where space efficiency and safety compliance are critical.
Final data subject to project specification and local code requirements.
| Item | Specification |
|---|---|
| Product Name | 50 tons vertical LCO2 vacuum insulated cryogenic storage tank |
| Storage Medium | Liquid CO₂ (LCO2) |
| Nominal Capacity | 50 Tons |
| Structure Type | Vertical, Double-Wall |
| Insulation Type | High Vacuum Multilayer Insulation |
| Design Temperature | Suitable for Liquid CO₂ low-temperature conditions |
| Design Pressure | Higher than operating pressure (customizable) |
| Working Pressure | Based on process requirement |
| Evaporation Rate | Optimized for bulk industrial CO₂ storage |
| Installation Type | Stationary Outdoor Installation |
| Monitoring System | Level gauge, pressure gauge, temperature interface |
| Safety System | Safety valve + vacuum relief device |
| Service Life | Designed per project drawing (20–30 years typical) |
For detailed drawings, pressure class, nozzle layout, and foundation load data, contact our engineering team.
The 50 tons vertical LCO2 vacuum insulated cryogenic storage tank is suitable for long-duration static storage, supporting industrial CO₂ bulk supply with controlled boil-off rate.
High vacuum interlayer reduces heat transfer
Lower evaporation loss compared with non-vacuum tanks
Vacuum valve port available for testing and monitoring
Designed to maintain insulation integrity during long-term operation
Safety valve for overpressure protection
Independent vacuum protection system
Pressure monitoring interface
Designed in compliance with applicable pressure vessel standards
This tank configuration is commonly selected for:
Bulk CO2 storage tank for beverage carbonation plant
LCO2 storage tank for dry ice production
Liquid CO2 tank for food processing factory
CO2 storage tank for welding gas supplier
Industrial CO2 bulk tank for chemical plant
LCO2 tank for CO2 recovery system integration
Used as a bulk LCO2 storage tank for beverage bottling plants, ensuring stable CO₂ supply for carbonation lines.
Integrated into:
Modified atmosphere packaging systems
Food freezing lines
Meat processing facilities
Acts as upstream liquid CO₂ storage for:
Dry ice pelletizer systems
Industrial dry ice blasting equipment
Suitable for:
CO₂ injection systems
Chemical reaction feedstock storage
Industrial gas filling stations
International buyers typically prioritize:
Controlled evaporation rate
Vacuum performance stability
Compliance with local pressure vessel codes
Long design life
Integration with vaporizer and pump skid
Foundation load compatibility
This model balances:
Storage capacity
Footprint efficiency
Transport feasibility
Cost-performance ratio
It is widely selected for medium-to-large CO₂ consumption facilities.
Available upon request:
Pressure build-up system
Cryogenic pump skid integration
Ambient vaporizer connection
Remote level monitoring
Customized nozzle layout
Food-grade internal treatment
Yes. The vacuum insulated double-wall structure supports long-term static storage of liquid CO₂ with controlled evaporation performance.
Evaporation rate depends on:
Vacuum level
Ambient temperature
Tank design pressure
Installation conditions
Project-specific evaporation data can be provided during technical confirmation.
No.
Working pressure is always lower than design pressure.
Design pressure is determined based on safety margin and code requirements.
The tank is equipped with a vacuum valve port that can be connected to a vacuum gauge for inspection and monitoring.
Typical design life ranges between 20–30 years depending on project specifications and regulatory requirements.
The 50 tons vertical LCO2 vacuum insulated cryogenic storage tank can be manufactured according to applicable pressure vessel codes and exported for overseas EPC projects.
Documentation available:
General arrangement drawing
Nozzle schedule
Pressure calculation sheet
Material certificate
Inspection and testing report
If you are sourcing a 50 tons vertical LCO2 vacuum insulated cryogenic storage tank for beverage plant, dry ice production, or industrial CO2 storage, provide the following for fast quotation:
Required operating pressure
Local standard compliance requirement
Installation location
Vaporizer or pump integration need
Estimated CO₂ consumption rate
Our engineering team will provide a tailored technical proposal and detailed parameter sheet.
